12-105 SmartAmp Bi-Directional 900 MHz: 5 Watt
This SmartAmp™ Bi-Directional amplifier is ideal for increasing the range of low power radio devices and to compensate for cable loss in certain installations.
Designed for extending the range of 900 MHz wireless radio devices, the SmartAmp™ is particularly effective when used with Direct Sequence or Frequency Hopping Spread Spectrum radio modems. This unit provides transmit power amplification as well as receive signal gain. The built-in dynamic power sensor in SmartAmp™ adjusts the Radio Frequency (RF) power output level by reading the input signal power. This Automatic Gain Control (AGC) Technology, Teletronics' patented technology effectively making the RF amplifiers "Plug & Play" delivers the maximum output power at various input levels while keeping the distortion at a minimum. Ideal for increasing the range of low power radio devices and to compensate for cable loss in certain installations.
OEM, Military & Export Version
Technical Specifications
Features:
5 Watt
Operating Range:
902 - 928 MHz
Operating Mode:
Bi-directional, TDD
Transmit Gain:
27 dB (can be customized to 33dB)
Frequency Response:
± 0.75 dB over operating range
Output Power:
5 Watt (+36 dBm) nominal
TX Input Power:
up to 20dBm (100mW)
Receiver Gain:
12 dB typical
Noise Figure:
3.5 dB typical
LED Inidicators:
RED
GREEN/ORANGE
Solid On: Power and Receiving mode Off: No Power
Blinking: Transmitting
Connectors:
N-type, female, 50 Ohm
Lightning Protection:
Quarter Wave Technology
DC Surge Protection:
Available
Power Consumption:
<2A @ 15 VDC (100% duty cycle)
Operating Temperature:
Amplifier: -30 °C to + 70 °C 12V DC injector: -30 °C to + 70 °C
