Ubiquiti AF-5XHD-US 5GHz airFiberX PtP 1Gbps Radio US

US Version

Ubiquiti continues to disrupt the wireless broadband market with revolutionary LTU technology that breaks through the limitations of 802.11 Wi-Fi technology. Designed for use in the 5 GHz frequency band, the new airFiber AF-5XHD is Ubiquiti's first LTU radio, offering greater channel bandwidths of up to 100 MHz, and more advanced RF components.

Pair the AF-5XHD with a compatible Ubiquiti® airFiber X antenna or RocketDish™ antenna for a complete 5 GHz Point-to-Point (PtP) solution.

Designed specifically for the Wireless ISP industry from the ground floor up, the AF-5XHD’s custom LTU silicon and radio architecture provide breakthrough performance. Its core communications processing engine surpasses the limitations inherent to generic Wi-Fi chips to provide low latency, long-range capability, DFS flexibility, higher constellations, and better power output, along with improved receive sensitivity.

The AF-5XHD features industry leading 21.2 bps/Hz spectral efficiency, line-rate data packet processing for up to 1.34 Gbps of real data throughput, and innovative xtreme Range Technology (xRT™).

• 4.8 - 6.2 GHz (Dependent on Regulatory Region)
• (2) RP-SMA Weatherproof
• (1) SMA Weatherproof
• (1) 10/100/1000 Ethernet Port
• (1) 10/100/1000 Ethernet Port Bluetooth v4.0
• 24V, 1A Gigabit PoE Adapter (Included)
• Passive PoE
• airFiber X Mount (Rocket Mount Compatible)
• GPS Pole Mount (Included)
