Power Management

KEY FEATURES:

• 30A Total Power on (2) A/B Banks
• Ping Watchdog, Echo, WiFi, Rest API
• Programmable using Lua
• Schedule or Instantly Reboot / Restart
• Emergency Shutoff Button

• • Number of DC inputs: 1 (3-pin terminal)
• • Min Voltage: 12 V
• • Max Voltage: 48 V
• • Max Power Consumption with Attachment: 100 W
• • Dimensions: 86 x 16 x 31 mm

KEY FEATURES:

• Power Options 3-60VDC, 12-120VAC
• Use Arduino, Rasberry, Pi or PIC
• Single Switch 4 Outlets, 1NC,2NO,1ON
• 12A Thermal Safety Circuit Breaker
• Professionally Built and Tested

• • Rugged and lightweight steel construction, occupies 2 RU in any standard equipment rack
• • Operates in dual or bridge-mono modes
• • Wide range of speaker impedances and outputs, including 2/4/8 Ohms and 70V or 140V
• • Excellent sound reproduction with low distortion
• • Advanced protection circuitry protects against overheating, overloads, and shorts

• • CMD Remote Management
• • 4x Integrated PoE Ports
• • 150W Typical Power per Port
• • LAN/PoE Galvanically Isolated
• • GigaKey Port Mapping

• • CMD Remote Management
• • 4x Integrated Terminal Ports
• • 500W Typical Power per Port

• • 150V Overvoltage Protection
• • Cambium Sync cnWave 5G Fixed Base
• • 2 Stages TVS-GDT
• • 3A per Port Simultaneously

• • New web interface: more intuitive with new graphics, new functionalities, new event log
• • New hardware: reduction of self-consumption, improving the input to output voltage drop
• • New cartridge: TER-CS high power and Cambium sync compatible over 4-poles connector
• • More power: up to 3A per port simultaneously, 12A per cartridge (PoE-CS and TER-CS).
