RF Elements

KEY FEATURES:

• Radio Connection:
• (2) Slide-On RP-SMA
• Works with: Cambium Networks / ePMP 1000 AP, ePMP 1000 CSM, ePMP 3000L, ePMP Force 300 CSM

Features:

• Gain: 24.4 dBi
• Frequency Range: 5180-6400 MHz
• Antenna Connection: TwistPort - Quick Locking Waveguide Port
• Environmental: IP65
• Pole Mounting Diameter: 40-80mm (we recommend as close to 80mm as possible)

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 15 dBi
• • Azimuth Beam Width -6 dB: H 90°/V 90°
• • Elevation Beam Width -6 dB: H 25°/V 25°
• • ± 20° Elevation, ± 20° Azimuth

Features:

• Gain stability across spectrum

• Wide Band Performance

• BackShield for cluster deployments

• Light & Compact

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 10.4 dBi
• Coverage: 80 Degree Beam Pattern

• • Radio Connection: 4x RP-SMA Connector
• • Pigtails: 4x RP-SMA Connector 750mm (29.5in)
• • Antenna Type: Horn
• • Materials: UV Resistant ABS Plastic, Polycarbonate, HDPE, Aluminum, Stainless Steel
• • Environmental: IP55

• • Radio Connection: 4x RP-SMA Female Connector
• • Pigtails: 4x RP-SMA Male Connector 750mm (29.5 inch)
• • Antenna Type: Horn
• • Materials: UV Resistant ABS Plastic, Polycarbonate, HDPE, Aluminum, Stainless Steel
• •Environmental: IP55

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 13.0 dBi
• • Azimuth Beam Width -6 dB: H 60°/V 60°
• • Elevation Beam Width -6 dB: H 60°/V 60°
• • ± 25°

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 10 dBi
• • Azimuth Beam Width -6 dB: H 90°/V 90°
• • Elevation Beam Width -6 dB: H 90°/V 90°
• • Mechanical Tilt: ± 25°

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 17 dBi
• • Azimuth Beam Width -6 dB: H 60°/V 60°
• • Elevation Beam Width -6 dB: H 25°/V 25°
• • Mechanical Adjustment: ±20° Elevation, ±20° Azimuth

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 17 dBi
• • Azimuth Beam Width -6 dB: H 60°/V 60°
• • Elevation Beam Width -6 dB: H 25°/V 25°
• • Mechanical Adjustment: ±20° Elevation, ±20° Azimuth

• • Antenna Connection: TwistPort - Quick-Locking Waveguide Port
• • Radio Connection: 2x RP-SMA female
• • Materials: Aluminum
• • Environmental: IP65
• • Temperature: -40°C to +60°C (-40°F to +140°F)

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 18.4 dBi
• Coverage: 30 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 16.2 dBi
• Coverage: 40 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180-6400 MHz
• Gain: 14.3 dBi
• Azimuth Beam Width: -6 dB H 50°/V 50°
• Elevation Beam Width: -6 dB H 50°/V 50°
• Mechanical Tilt: ±25°
• Pole Mounting Diameter: 30-90mm

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 13.2 dBi
• Coverage: 60 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 11.5 dBi
• Coverage: 70 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 10.4 dBi
• Coverage: 80 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6000 MHz
• Connectors:TwistPort
• Gain: 16 dBi
• Azimuth Beam: H 90° / V 90°
• Elevation Beam: H 25° / V 25°

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 16.2 dBi
• Coverage: 40 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 11.5 dBi
• Coverage: 70 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 9.6 dBi
• Coverage: 90 Degree Beam Pattern

KEY FEATURES:

• Aluminum Enclosure IP65
• Mounting Diameter 50-70 mm
• Works with: RouterBoard RB912, RB911, RB711, RB433, RB411

KEY FEATURES:

• CPE enclosure
• Dual polarization antenna
• Frequency Range: 2400 - 2485 MHz
• Gain: 13.7 dBi
• IP65 rated

Features:

• Gain: 24 dBi
• Frequency Range: 5150-5950 MHz
• Antenna Connection:Waveguide Port
• Environmental: IP65
• Pole Mounting Diameter: 20-55mm (recommend as close to 55mm as possible)

KEY FEATURES:

• Frequency Range: 4900 - 6200 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 24 dBi
• Coverage: 11 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 14.3 dBi
• Coverage: 50 Degree Beam Pattern

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:(2) N type Female
• Gain: 9.6 dBi
• Coverage: 90 Degree Beam Pattern

Features:

• Gain: 21.2 dBi
• Frequency Range: 5180-6400 MHz
• Antenna Connection: TwistPort - Quick Locking Waveguide Port
• Environmental: IP65
• Pole Mounting Diameter: 40-80mm (we recommend as close to 80mm as possible)

Features:

• Gain: 27 dBi
• Frequency Range: 5150-5950 MHz
• Antenna Connection: Waveguide Port
• Environmental: IP65
• Pole Mounting Diameter: 20-55mm (recommend as close to 55mm as possible)

Features:

• Gain: 21 dBi
• Frequency Range: 5150-5950 MHz
• Antenna Connection: Waveguide Port
• Environmental: IP65
• Pole Mounting Diameter: 20-55mm (recommended as close to 55mm as possible)

KEY FEATURES:

• Radio Connection:
• (2) Slide-On RP-SMA
• Works with: Mimosa / C5C

• • Radio Connection: Wave Guide
• • Works with: Ubiquiti; IsoStation, IsoStation 5AC, IsoStation M5, PrismStation 5AC

• • (2) Slide-On RP-SMA
• • Works with: Ubiquiti Networks Rocket M5

KEY FEATURES:

• Wall Mounting: Yes
• Pole Mounting Diameter: 50-70 mm
• Works with:
• RouterBoard SXT Lite5, SXT HG, SXT SA, SXT Lite2, SXT G-2HnD

KEY FEATURES:

• Wall Mounting: Yes
• Pole Mounting Diameter: 50-70 mm
• Works with:
• RouterBoard SXT

KEY FEATURES:

• Radio Connection:
• (2) Slide-On RP-SMA
• Works with: Ubiquiti Networks R5AC-Lite

KEY FEATURES:

• Shielded Sleeve
• Radio Connection:
• (2) Right Angle MMCX
• RouterBOARD Series 4, 7, 9, M11

KEY FEATURES:

• Radio Connection:
• (2) Slide-On RP-SMA
• RouterBOARD Series 4, 7, 9, M11

• • Radio Connection: TwistPort Waveguide Connector
• • Antenna Type: Parabolic Dish
• • Materials: UV Resistant ABS plastic, Aluminum, Stainless Steel
• • Environmental: IP65

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 13.2 dBi
• Coverage: 60 Degree Beam Pattern

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 18.0 dBi
• • Azimuth Beam Width -6 dB: H 30°/V 30°
• • Elevation Beam Width -6 dB: H 30°/ V 30°
• • Mechanical Tilt: ± 25°

• • Antenna Connection: TwistPort - Quick-Locking Waveguide Port
• • Radio Connection: 2x Slide-On RP-SMA
• • Materials: UV Resistant ABS plastic, Aluminum Alloy
• • Flame Rating: UL 94 HB
• • Environmental: IP65

KEY FEATURES:

• Frequency Range: 5180 - 6400 MHz
• Connectors:TwistPortTM - Quick Locking Waveguide Port
• Gain: 18.4 dBi
• Coverage: 30° Beam Pattern

KEY FEATURES:

• Radio Connection:
• (2) Threaded RP-SMA
• Works with ANY connectorized radio

• • Frequency Range: 4900 - 7125 MHz
• • Gain: 15 dBi
• • Azimuth Beam Width -6 dB: H 90°/V 90°
• • Elevation Beam Width -6 dB: H 25°/V 25°
• • ± 20° Elevation, ± 20° Azimuth

• • Antenna Connection: TwistPort - Quick Locking Waveguide Port
• • Radio Connection: 2x Slide-On RP-SMA and 1x SMA for GPS
• • Materials: Insert - Aluminium Alloy; Adaptor - UV stabilized and weather resistant ABS plastic
• • Flame Rating: UL 94 HB
• • Temperature: -40°C to +60°C (-40°F to +140°F)
